Hoppt® , a family-owned Singapore based company founded in 1975 by Mr. Tan Poh Kwang, was Singapore’s very first and only manufacturer of light construction equipment. Hoppt vision is to be the leading manufacturer of light-to-medium construction equipment, and other industrial products by providing our customers with superior quality products that provide reliable performance along with dependable customer sales and service support.
| MODEL | DVR28 |
|---|---|
| MACHINE DIMENSION - L x W x H (mm) | 2,594 x 1,322 x 2,852 |
| Height - Top of the Steering Wheel - (mm) | 1,740 |
| Height - Top of ROPS - (mm) | 2,852 |
| WEIGHT - (kg) | Operating Weight - 2,780 Shipping Weight - 2,840 |
| DRUM WEIGHT - (kg) | Static Front - 688 Static Rear - 686 |
| DRUM SIZE - (mm) | Width (1,200) Option (1,000), Diameter (700), Shell Thickness (15) Side Clearance (50), Curb Clearance (648), Chamfered Edge Finishing |
| DRUM WIPER TYPE | Spring-Leaded Self-Adjusting Steel Wiper 66 (3,960) |
| VIBRATION FREQUENCY - Hz (vpm) | Nominal Amplitude 0.4 |
| VIBRATING SYSTEM | Gear Pump - POCLAIN Hydraulics, FRANCE Motors - CASAPPA, ITALY Front/Both |
| CENTRIFUGAL FORCE - (kN) | 28 |
| PROPULSION | DRUM DRIVE - Axial Piston Pump with Variable Displacement and 2 Radial Piston Motors from POCLAIN Hydraulics, FRANCE |
| SPEED - (km/h) | 10 - Highest Speed |
| BRAKES - Gradability (Theoretical) | 30° PARKING - SAHR (Spring-Applied Hydraulically Released) |
| STEERING SYSTEM AND DESIGN | 1 Cylinder, Double-Acting Hydraulic System with a Maintenance-Free Centre Pivot Articulation of 34° Outside Turning Radius - 3,600 mm |
| WATER SYSTEM | Pressurised Electric Diaphragm Pump Filters of 100 Mesh Screen @ Nozzle with 80 Mesh In-Line |
| TANK CAPACITY - (litre) | Water Tank - 205 Fuel Tank - 50 Hydraulic Tank - 68 |
